ACCESS-MOPPy (Model Output Post-processor in Python)

ACCESS-MOPPy is a CMORisation tool designed to post-process ACCESS model output and produce CMIP-compliant datasets.

Watch the quick start (10 min)

CMORising ACCESS output for CMIP7 FastTrack — a quick start with ACCESS-MOPPy — a narrated walkthrough of the whole NCI Gadi workflow, from loading the analysis3 environment to watching the batch run. It follows the quick start guide step for step.

Note

The narration voice in the video is synthetic and the script was drafted with AI assistance from this documentation. The workflow it shows is the real, maintained one.

Key Features

• Python API for integration into notebooks and scripts
• Batch processing system for HPC environments with PBS
• Real-time monitoring with web-based dashboard
• Flexible CMORisation of individual variables
• Dask-enabled for scalable parallel processing
• Cross-platform compatibility (not limited to NCI Gadi)
• CMIP6 and CMIP7 FastTrack support
• Publication QC: physical-range checks, the WCRP compliance checker, and diagnostic plots — see below

From native ACCESS output to publishable CMIP7

For CMIP7 Fast Track, ACCESS-MOPPy takes raw ACCESS model output — UM fields files, MOM and CICE history — and produces files that are ready to publish: CMORised, checked against physical ranges, validated against the CMIP controlled vocabularies, and plotted for a human to look at. The four stages run in that order, from a notebook or from a batch run on NCI Gadi.

Reads ACCESS-ESM1.6 atmosphere, land, ocean and sea-ice output directly and writes CMIP7 files — branded variable names, CMIP7 global attributes, DRS paths and file names. No CMOR library: the rewrite is built on xarray and dask, so the same code runs in a notebook or across hundreds of PBS jobs.

→ Fast Track quick start · baseline runs · batch processing

Every CMIP7 file written is checked against a per-variable physical envelope — 293 ACCESS-ESM1-6 variables, with experiment-specific overrides — plus units, missing-value and finite-value checks. The bounds are broad on purpose: they catch a unit, sign or conversion error without rejecting a plausible extreme.

The rules themselves are data, and you can read them without touching a file:

moppy-qc --show-ranges --variable tas --variable pr --experiment piControl

variable  units       min  max  rule
--------  ----------  ---  ---  ---------
tas       K           180  325  piControl
pr        kg m-2 s-1  0    0.1  default

Add --format json for the machine-readable form, ready to pipe into jq or attach to a data-quality record.

→ Every rule, rendered and filterable · running the checks

Runs the CF suite (cf:1.11) and the WCRP CMIP suite (wcrp_cmip7:1.0, backed by esgvoc) on the first file each variable publishes — metadata, controlled-vocabulary values, DRS path and file name. A failure stops that variable before any further file is written, and the JSON report is kept either way. One line of batch config turns it on:

compliance_check: true

→ Enabling it in a batch run · checker backends

Two PNGs per output file: a spatial snapshot of the first timestep, and a timeseries of the global mean with min/max shading and standard deviation. A published ACCESS-ESM1-5 CMIP6 series can be overlaid on the timeseries, so drift against the previous submission is visible at a glance.

moppy-qc-plots /scratch/cmor_output/CMIP7 --comparison-store /g/data/cmip6_store

→ Plots from a batch run · regenerating them

Note

Stages 2 and 4 run inside the CMORisation job, and stage 3 is one line of batch configuration. The batch report (moppy_batch_report_<UTC>.json) collects the results of all three, so a whole experiment can be signed off from a single file.

Installation

ACCESS-MOPPy requires Python >= 3.11.

On NCI Gadi (recommended for ACCESS users)

The conda/analysis3-latest environment maintained by ACCESS-NRI already includes access_moppy and its dependencies, so no pip install is needed:

module use /g/data/xp65/public/modules
module load conda/analysis3-latest

All command-line tools (moppy-cmorise, moppy-tui, moppy-qc, …) are available immediately after loading the module. You'll need membership of the xp65 NCI project for the module itself, plus whichever projects hold the model output and CV/table data you're processing. Pin a dated release (e.g. conda/analysis3-26.04) instead of -latest if you need a reproducible environment for a production run.

From PyPI

pip install access_moppy

From source

The controlled vocabularies under src/access_moppy/vocabularies/ are pulled in as git submodules. If you install from a local clone, initialise them first, otherwise the CMOR tables/CVs will be missing and imports will fail with an error like No module named 'access_moppy.vocabularies.CMIP6_CVs':

git clone --recurse-submodules https://github.com/ACCESS-NRI/ACCESS-MOPPy.git
cd ACCESS-MOPPy
pip install .

If you already have a clone without the submodules populated, run:

git submodule update --init --recursive
pip install .

Quick Start

New to CMORisation on Gadi? Watch the 10 minute walkthrough first.

Interactive Usage (Python API)

import glob
from access_moppy import ACCESS_ESM_CMORiser

# Select input files
files = glob.glob("/path/to/model/output/*mon.nc")

# Create CMORiser instance
cmoriser = ACCESS_ESM_CMORiser(
    input_data=files,
    compound_name="Amon.pr",  # table.variable format
    experiment_id="historical",
    source_id="ACCESS-ESM1-5",
    variant_label="r1i1p1f1",
    grid_label="gn",
    activity_id="CMIP",
    output_path="/path/to/output"
)

# Run CMORisation
cmoriser.run()
cmoriser.write()

Batch Processing (HPC/PBS)

For large-scale processing on HPC systems:

1. Create a configuration file (batch_config.yml):

variables:
  - Amon.pr
  - Omon.tos
  - Amon.ts

experiment_id: piControl
source_id: ACCESS-ESM1-5
variant_label: r1i1p1f1
grid_label: gn

input_folder: "/g/data/project/model/output"
output_folder: "/scratch/project/cmor_output"

file_patterns:
  Amon.pr: "output[0-4][0-9][0-9]/atmosphere/netCDF/*mon.nc"
  Omon.tos: "output[0-4][0-9][0-9]/ocean/*temp*.nc"
  Amon.ts: "output[0-4][0-9][0-9]/atmosphere/netCDF/*mon.nc"

# PBS configuration
queue: normal
cpus_per_node: 16
mem: 32GB
walltime: "02:00:00"
scheduler_options: "#PBS -P your_project"
storage: "gdata/project+scratch/project"

worker_init: |
  module load conda
  conda activate your_environment

2. Submit batch job:

moppy-cmorise batch_config.yml

3. Monitor progress at http://localhost:8501

Batch Processing Features

The batch processing system provides:

• Parallel execution: Each variable processed as a separate PBS job
• Real-time monitoring: Web dashboard showing job status and progress
• Automatic tracking: SQLite database maintains job history and status
• Error handling: Failed jobs can be easily identified and resubmitted
• Resource optimization: Configurable CPU, memory, and storage requirements
• Environment management: Automatic setup of conda/module environments

Monitoring Tools

• Streamlit Dashboard: Real-time web interface at http://localhost:8501
• Command line: Use standard PBS commands (qstat, qdel)
• Database: SQLite tracking at {output_folder}/cmor_tasks.db
• Log files: Individual stdout/stderr for each job

File Organization

work_directory/
├── batch_config.yml          # Your configuration
├── cmor_job_scripts/          # Generated PBS scripts and logs
│   ├── cmor_Amon_pr.sh       # PBS script
│   ├── cmor_Amon_pr.py       # Python processing script
│   ├── cmor_Amon_pr.out      # Job output
│   └── cmor_Amon_pr.err      # Job errors
└── output_folder/
    ├── cmor_tasks.db         # Progress tracking
    └── [CMORised files]      # Final output

Documentation

Full documentation: https://access-moppy.readthedocs.io

• Quick start: Run your first CMORisation on Gadi
• Tutorials: Notebook walkthroughs
• How-to guides: Batch processing, QC validation, ESMValTool, ILAMB
• Reference: CLI, configuration keys, QC range rules, Python API
• Example Configuration: src/access_moppy/examples/batch_config.yml

Test Data Override

Integration and end-to-end tests require an external test-data tree set via the ACCESS_MOPPY_DATA_ROOT environment variable.

• Covered tests: full CMOR integration and end-to-end real-file tests
• No fallback: test-data fixtures in tests/data/ are not used by these tests
• Requirement: ACCESS_MOPPY_DATA_ROOT must point to a valid dataset root containing output*/atmosphere/netCDF, output*/ocean, and output*/ice

Example:

export ACCESS_MOPPY_DATA_ROOT=/path/to/CMIP7_Test_data/esm-historical
pixi run -e dev python -m pytest tests/integration/test_full_cmorisation.py
pixi run -e dev python -m pytest tests/integration/test_cmip7_baseline_cmorisation.py
pixi run -e dev python -m pytest tests/e2e/test_end_to_end.py

CMIP7 baseline test note:

• tests/integration/test_cmip7_baseline_cmorisation.py runs one case per CMIP7 baseline variable listed in src/access_moppy/examples/batch_config_esm1-6_cmip7_baseline.yml
• By default, this suite checks end-to-end CMORisation success (run/write/output)
• To additionally enforce WCRP compliance-checker validation for this suite, set ACCESS_MOPPY_BASELINE_VALIDATE_WCRP=1

Example with strict WCRP validation enabled:

export ACCESS_MOPPY_DATA_ROOT=/path/to/CMIP7_Test_data/esm-historical
export ACCESS_MOPPY_BASELINE_VALIDATE_WCRP=1
pixi run -e dev python -m pytest tests/integration/test_cmip7_baseline_cmorisation.py --validation-tool=wcrp

Current Status

• Stable project status: ACCESS-MOPPy is suitable for supported CMORisation workflows and ongoing production-oriented use.
• Ocean variables: Ocean variables are supported, including dedicated ocean CMORisers and resource guidance for large 3D variables.
• Variable mapping: Mapping coverage continues to be reviewed and improved for CMIP6/CMIP7 compliance.

Support

• Issues: Submit via GitHub Issues
• Questions: Contact ACCESS-NRI support
• Contributions: Welcome via Pull Requests

License

ACCESS-MOPPy is licensed under the Apache-2.0 License.
