Embed per-monitor DPI awareness and maintain the verified OGRE 13.6.5 renderer patch required for context-safe window replacement, runtime GL options and correct fullscreen client geometry. Validation: clean Release build, DPI and 3440x1440 fullscreen probes, three GL3Plus variants and the patch reverse check passed; version 0.7.1 remains unchanged because this is unreleased work and the project has no changelog.
Apply display, input, audio, gameplay, minimap, shadow and negotiated nickname changes to the running session while preserving rollback for failed window or input transitions and keeping the 3440x1440 navigation visible. Validation: clean Release and Debug builds, packet tests, DPI, layout and GL3Plus probes passed; the user confirmed the reported resolution, fullscreen, cursor, flicker and navigation failures are fixed. Version 0.7.1 remains unchanged because this is unreleased work and the project has no changelog.
The spells tab put its ten buttons in a single row of 60 pixel squares running out to x=700. The pane they live in is the window width minus the 200 pixels of minimap, so at the 800 wide minimum window it is 600 pixels across, and the last two spells, Weakness and the Eye of Evil, hung past its right edge where they could be neither seen nor clicked. Only a window at least 900 wide showed the whole row, and nothing said so. The rooms tab solved the same problem long ago: two rows of 40 pixel buttons. The spells tab now uses the same shape, five spells to a row, ending at x=300 with room to spare at any size the game accepts. The cooldown bar inside each button now covers exactly its button too, instead of overhanging 20 pixels on both sides, which with narrower buttons would have bled half way across the neighbours. The rooms tab had the tail of the same bug: the temple and portal buttons the editor uses sat at x=570 to 690, past the same edge. They join the end of the second row instead. (cherry picked from commit 10db1cb)
Remove depleted fills and borders while preserving surviving health segments and the centre. Update player guidance and add the 200-check texture regression. No release version or protocol change is needed; the existing PR documents this unreleased feature correction.
# Conflicts: # source/entities/Creature.cpp
Replace the hardcoded dependency, Python and Visual Studio locations in the Windows scripts with a shared windows-paths.ps1. The defaults derive from the current user profile and can be overridden with OD_DEPS_ROOT, OD_PYTHON_ROOT and OD_VS_PATH.
Replace the auto declarations introduced by this branch with explicit types, as requested in issue tomluchowski#42 and required by CLAUDE.md. No behavioural change.
Replace the auto declarations introduced by this branch with explicit types, as requested in issue tomluchowski#42 and required by CLAUDE.md. No behavioural change.
Replace the auto declarations introduced by this branch with explicit types, as requested in issue tomluchowski#42 and required by the project coding guidelines. No behavioural change.
The middle button rotates the camera and, on press, also opened the stats window of the creature under the pointer. Rotating over creatures therefore opened windows the player never asked for. The window now opens when the button is released without the pointer having moved more than a few pixels; a middle drag only rotates. Also explain the KO checkbox in the player settings with a tooltip.
The creature and tile info windows were built in code with a fixed 380 x 400 pixel size that was never scaled while the fonts were, so the text was huge and cut off. They are now loaded from the new gui/WindowStats.layout through Gui::createInfoWindow() and registered for UI scaling like every other layout: fixed 540 x 490 layout units, centred, not resizable (moving and closing stay), text top aligned and word wrapped, body text in MedievalSharp-8 and headings in MedievalSharp-10. A creature lists its next four destinations and the total count, so the text fits the fixed window. Check: source/tests/check_info_window.py (no sizing, fixed size, body font, formatting, both entities use the layout). Depends on the GUI scaling (tomluchowski#209) for Gui::registerWindowHierarchy().
…e it Add compose on raw RGBA buffers with alpha blending in slot order and helmet damage limited to the helmet alpha for Knight and Cultist, the shared tint path with a separate base tint config, a client side picture cache with LRU and size limits, and the fallback signal for missing manifests.
…nbook Fill the profile page and the creature card from the composed appearance picture and fall back to the tinted preview portrait only when there is none. Add profile remarks that match the parts (config/dungeonbook-quirks.cfg), chosen with a fixed hash from name and appearance, a separation check for the creature bar, tests for remarks and for two clients plus a late joiner, and the outfit slot in the manifest loader. Existing notification order checks now ignore the appended appearance notification.
…ication order checks skip the appended appearance entry
…er creature The neutral bases have no hair, eyes or beards, so their colours are applied to the chosen parts before composing (part tint file, same PortraitTint code path and name based colour choice). Hair and beard parts share one colour; eye irises are tinted through measured ellipse regions for the options that could be separated cleanly. The skin amplitude of the bases comes from a base-skin entry, so bases delivered without an amplitude still vary per creature. Quirk remarks now use the real option names of the manifests, are placed after status and latest post so the card layout of those stays put, and the card gets room for them. New static checks cover the tint files, the profile layout and the test registration.
…ad of fixed loop bounds
The profile page (creature card and Dungeonbook share it) now has a scrollbar at its right edge that appears only when the rows are higher than the page, and all rows move with it. The card is taller so the usual content with remarks fits without scrolling. The layout check models the heights for several resolutions and user scales, typical and worst case.
… wheel scrolling, golden test - First spawn rolls until the look is free; a duplicate is only accepted when every combination of the catalog id is already in use (64 bit saturating count, no fixed number of tries). - The manifest registry gives failed manifests another chance on request: the server retries before it derives a late look, the client every few seconds; a failure that stays the same is logged once. - Composing is plain source-over in manifest order; the scar and helmet masks are baked into the part images, so the runtime clipping of scars to the helmet is gone. - The mouse wheel scrolls the profile page (card and Dungeonbook) while its scrollbar is shown; in the Dungeonbook the profile leaves a fixed room for the recent posts and scrolls inside. - Golden test of composing plus tinting with an exactly derivable scene and a script that recomputes it.
Orc and Troll eyes use fire, Kobold eyes use glow (with the colour limits of the old regions), and Monk (female) hair uses hair_brown, with the same palette colours in the same order and the same region names as portrait-tints.cfg, so a creature gets the same palette colour as in the old portrait. A block for a catalog id now replaces the generic block of that part. The tint check compares the palettes with the old file and the catalog ids with the old regions.
…he iris - A creature whose stored look was never checked against a manifest (loaded or spawned without one) is checked on the retry loop as soon as the manifest is valid; removed options are replaced stably from the name and the clients are told when the look changed. The client display replaces removed options the same way. - Eye tint regions were audited against the artwork: the Kobold eye patch option is left untinted, the Kobold round option and the Orc options got tighter limits, and a new check enforces a limit for tinted pixels outside the iris area.
…heck A creature without a catalog id remembers that and is not looked at again until the registry's catalog generation changes. The registry remembers which catalog folders exist and forgets that once per retry period for all creatures together, so a folder that appears later is still found without a file lookup per creature and upkeep.
…, add the brown hair palette and name the meshes as the creature definitions do Without the header the first palette was not read, and the mesh names without the model suffix never matched a creature, so no portrait was tinted. The Dungeonbook part tints refer to the brown hair palette.
…compile or expected the wrong tint entries
… which only exists where held creatures are shown at the pointer
The editor region, level script and sandbox score checks test code that this change does not contain, so they move to the changes that add that code.
The records and the neutral base notes named the folder of the local image generator. They now only name the generated file, so no personal path is stored in the repository. The images are unchanged.
The two overlay textures CreatureExperience.png and CreatureRecovery.png are part of this branch but had no CREDITS entry. Add one with source, licence and the AI-generated mark.
The remarks block (declaration of quirks, its filling and the two text updates) was present twice in a row, which stopped the file from compiling because quirks was declared twice. One copy is kept, as in the main line.
… a real manifest" This reverts commit b0c6ca9.
This branch has not been deployed
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
2 participants
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Gives each creature its own portrait colour variation (hair, beard, eyes, skin, teeth), configured in config/portrait-tints.cfg and applied in the profile card and the Dungeonbook. The variation is deterministic per creature. The population panel and hand icons are unchanged.
Stacked on #247 (feature/creature-social-feed) and through it on the profile card PR. Review this PR alone: compare of the 1 own commit.
Related: #220 (standalone portrait exporter, a different topic; this PR does not change the exporter tool) and #225 (portrait assets and the CreaturePortrait files this builds on).
These previews also use the gender images of the next PR.
Verification: Release build of this branch; check_creature_portrait_tints.py passes (34 meshes). Mario tested the integrated build in game. No gameplay, network or save game effect.
Update 2026-10: aligned with the current development state
Checked against the current development branch. Taken over from it, with only the lines each commit changes:
Further commits in this update: credits for the two overlay textures CreatureExperience.png and CreatureRecovery.png (AI-generated), removal of provenance wording in the portrait notes and a GUI comment, and removal of a duplicated declaration in the creature info page. A first attempt at the tint commit replaced the whole file; it was reverted and redone with only the commit's own lines (both stay in the history).
The remaining own files still differ from the development branch because of later commits that belong to other features and are not part of this PR (neutral portrait bases and measured tint regions, gender portraits, composed Dungeonbook pictures, shared portrait renderer).
Validation: release build verified on the pushed tip.
